GRC构件在建筑中的五个要点

来源:http://www.aswjc.com/ 发布人:admin 发布时间:2022-10-25

GRC构件的成型几乎不受形状限制,采用GRC构件精心设计建筑师各种富有想像力的设计,可分别创出恢宏壮观、古朴典雅、自然秀美和清新幽雅的建筑和环境。下面讲讲山东GRC构件在建筑中的五个要点。
The forming of GRC components is almost unlimited by the shape. The use of GRC components to carefully design various imaginative designs by architects can create magnificent, simple and elegant, natural and beautiful buildings and environments. Here are five key points of Shandong GRC components in architecture.
1、GRC构件按顺序就整幢建筑应由上往下挂,上中要以水平线为准,GRC构件底层的挂好后,要用靠尺检查校正,确保整幢建筑线条立面上下垂直,不得有上下左右不齐的现象,制品间离缝控制在5mm左右。
1. GRC components shall be hung from top to bottom in order, and the upper and middle parts shall be subject to the horizontal line. After the bottom layer of GRC components is hung, it shall be checked and corrected with a guiding rule to ensure that the elevation of the whole building line is vertical from top to bottom, and there shall be no unevenness from top to bottom, left to right, and the gap between products shall be controlled at about 5mm.
2、GRC构件的设计重要性:上面讲述到GRC构件的好处就是可以自由设计,这是GRC构件作为装饰材料的一大优势,同时也是人们选着GRC构件的原因,如果厂家能将人们所需要的装饰材料提供出来,那么自然就深受人们的青睐,但是由于设计以及制作都是需要专门水平以及能力,所以厂家是否拥有专门的技术以及团队就成为是否能制作出GRC构件的关键。
2. Importance of GRC component design: The advantage of GRC component is that it can be designed freely, which is a major advantage of GRC component as decorative material, and also the reason why people choose GRC component. If the manufacturer can provide the decorative materials that people need, it will naturally be favored by people. However, due to the special level and ability required for design and production, Therefore, whether the manufacturer has special technology and team becomes the key to make GRC components.
3、接缝处采用GRC构件加丙烯酸型胶粘剂拌匀后配置专用胶粘剂分三次嵌满接缝,每次嵌缝间隔24h以上。制品与基层交接处用密封膏嵌缝,与铝合金表面的交接处用中性硅酮密封胶密封。
3. The joints shall be filled with special adhesive for three times after being mixed with GRC components and acrylic adhesive, with the interval of each time more than 24h. The joint between products and base course shall be caulked with sealant, and the joint with aluminum alloy surface shall be sealed with neutral silicone sealant.
山东GRC构件
4、质量得以保障:虽然GRC构件生产制作需要用到经过许多环节,无论是在设计还是在生产制作,都需要保持着十二分精神。因为只有的团队才能确保构件的质量不受到外界的影响,更是保障GRC构件不受破坏的关键。
4. Quality can be guaranteed: Although GRC component production needs to go through many links, whether in design or production, we need to maintain the spirit of twelve points. Because only a professional team can ensure that the quality of components is not affected by the outside world, which is the key to ensure that GRC components are not damaged.
5、建筑物连接结构为空心块状砌体结构,砌体强度大于Mu7.5,砂浆强度大于M5,砌体厚度大于等于370mm采用置换块,置换块应采用C20级以上膨胀细石混凝土灌注,厚度240mm高度和宽度不小于240mm,锚栓应安装在置换块中心位置,不符合上述要求之一时,应采用焊接连接方式安装。
5. The connecting structure of the building is hollow block masonry structure. The masonry strength is greater than Mu7.5, the mortar strength is greater than M5, and the masonry thickness is greater than or equal to 370 mm. The replacement block shall be poured with C20 or higher expansive fine aggregate concrete, with a thickness of 240 mm and a height and width of not less than 240 mm. The anchor bolt shall be installed in the center of the replacement block. If one of the above requirements is not met, the replacement block shall be installed by welding.
GRC构件不仅分层细致,表面光滑度高,而且气密性,抗压强度,抗裂性,耐火性和耐湿性也都是高质量的。它适用于创建各种空间设计设计,例如酒店、别墅、剧院、旅游景点和幕墙等。您有需求就来我们这里http://www.aswjc.com进行联系咨询!
GRC members not only have fine layers and high surface smoothness, but also have high air tightness, compressive strength, crack resistance, fire resistance and moisture resistance. It is suitable for creating various space designs, such as hotels, villas, theaters, tourist attractions and curtain walls. Come here if you need http://www.aswjc.com Get in touch!
